OVERVIEW
The Sliding jaw mandrel is a special type of internal diameter clamping device with multiple jaws 3, 6, 9 and 12, arranged as component profile. This kind of mandrel can be used to hold irregular surface as well as conical and circular surfaces.
Stroke
26mm
Jaw travel
3.6mm
Gripping Force
55kN per jaw
| Stroke | 26mm | |
| Jaw Travel | 3.6mm | |
| Axial Pull | Jaw set-1 | 08kN |
| Jaw set-2 | 12kN | |
| Gripping Force | 55kN per Jaw | |
