Electrospindle Manual Tool change

CATEGORY: ALUMUNIUM / PLASTICS LINE
Back Enquire

OVERVIEW

Manual toolchange electro-spindles are designed for high power density and compactness, making them ideal for wood, plastic and aluminium.

They are realized to suit better at all different conditions of using both for milling, drilling and edgebending.



The wide range of powers, from 0,35kW to 13,5kW with rotation speed up to 24.000 rpm allow a wide-using versatility that covers all kind of working conditions with axials and radial force. “Quality without Compromises” system is the rule in HSD organisation and guarantees unquestionable service and the highest reliability.

HSD is the leading world company in the production of electrospindles.

MT1090 - Y616109046

Kw 3,5 S1 - HSK C50

18.000rpm - 380V - right rotation

MT1090 - Y616109046

TECHNICAL SPECIFICATIONS

Power S1: 3,5Kw

Connection type: HSK C50

Rated voltage: 380V

Rated speed: 12.000rpm

Max speed: 18.000rpm

Rotation: Right

Weight: 13kg

Cooling: forced air

MT1090 - Y6162Y0049

Kw 5-S1/6-S6 - HYDRO

18.000rpm - 380V - right/left rotation

MT1090 - Y6162Y0049

TECHNICAL SPECIFICATIONS

Power S1/S6: 5Kw/6Kw

Connection type: Hydro Quick-Change Tooling

Rated voltage: 380V

Rated speed: 12.000 rpm

Max speed: 18.000rpm

Rotation: Right/Left

Weight: 12kg

Cooling: forced air

MT1055 - H6162H0086

Kw 1,00-S1/1,30-S6

connection ER20 collet - 30.000rpm - LIQUID cooling 380V - right rotation

MT1055 - H6162H0086

TECHNICAL SPECIFICATIONS

Power S1/S6: 1,00Kw/1,30Kw

Connection type: Collet ER20

Rated voltage: 380V

Rated speed: 18.000rpm

Max speed: 30.000rpm

Rotation: Right

MT1055 - H6162H0087

Kw 1,00-S1/1,30-S6

connection ER20 collet - 30.000rpm - LIQUID cooling 220V - right rotation

MT1055 - H6162H0087

TECHNICAL SPECIFICATIONS

Power S1/S6: 1,00Kw/1,30Kw

Connection type: Collet ER20

Rated voltage: 220V

Rated speed: 18.000rpm

Max speed: 30.000rpm

Rotation: Right

MT1055 - Y6162Y0002

Kw 0,65-S1/0,85-S6

- R20 collet - 12.000rpm - rated voltage 380V - right rotation

MT1055 - Y6162Y0002

TECHNICAL SPECIFICATIONS

Power S1/S6: 0,65Kw/0,85Kw

Connection type: Collet ER20

Rated voltage: 380V

Rated speed: 12.000 rpm

Max speed: 12.000rpm

Rotation: Right

MT1055 - Y6162Y0003

Kw 1-S1/1,30-S6

connection ER20 collet - 18.000rpm - rated voltage 380V - right rotation

MT1055 - Y6162Y0003

TECHNICAL SPECIFICATIONS

Power S1/S6: 1Kw/1,30Kw

Connection type: Collet ER20

Rated voltage: 380V

Rated speed: 18.000 rpm

Max speed: 24.000rpm

Rotation: Right

MT1055 - Y6162Y0004

Kw 0,65-S1/0,85-S6

connection ER20 collet - 12.000rpm - rated voltage 220V - right rotation

MT1055 - Y6162Y0004

TECHNICAL SPECIFICATIONS

Power S1/S6: 0,65Kw/0,85Kw

Connection type: Collet ER20

Rated voltage: 220V

Rated speed: 12.000 rpm

Max speed: 12.000rpm

Rotation: Right

MT1055 - Y6162Y0005

Kw 1-S1/1,30-S6

connection ER20 collet - 18.000rpm - rated voltage 220V - right rotation

MT1055 - Y6162Y0005

TECHNICAL SPECIFICATIONS

Power S1/S6: 1Kw/1,30Kw

Connection type: Collet ER20

Rated voltage: 220V

Rated speed: 18.000 rpm

Max speed: 24.000rpm

Rotation: Right

MT1055 - Y6162Y0033

Kw 1-S1/1,30-S6

connection ER20 collet - 18.000rpm - rated voltage 380V - right rotation

MT1055 - Y6162Y0033

TECHNICAL SPECIFICATIONS

Power S1/S6: 1Kw/1,30Kw

Connection type: Collet ER20

Rated voltage: 380V

Rated speed: 18.000 rpm

Max speed: 24.000rpm

Rotation: Right

MT1055 - Y6162Y0077

Kw 1-S1/1,30-S6

connection ER20 collet - 18.000rpm - rated voltage 380V - right rotation

MT1055 - Y6162Y0077

TECHNICAL SPECIFICATIONS

Power S1/S6: 1Kw/1,30Kw

Connection type: Collet ER20

Rated voltage: 380V

Rated speed: 18.000 rpm

Max speed: 24.000rpm

Rotation: Right

MT1055 - H6162H0088

Kw 1-S1/1,30-S6

connection ER20 collet - 18.000rpm - rated voltage 220/380V - right rotation

MT1055 - H6162H0088

TECHNICAL SPECIFICATIONS
Power S1/S6: 1Kw/1,30Kw

Connection type: Collet ER20

Rated voltage: 220/380V

Rated speed: 18.000 rpm

Max speed: 26.000rpm

Rotation: Right

MT1073 - Y6162Y0006

Kw 1-S1/1,30-S6

connection ER25 collet - 12.000rpm - rated voltage 380V - right rotation

MT1073 - Y6162Y0006

TECHNICAL SPECIFICATIONS

Power S1/S6: 1Kw/1,30Kw

Connection type: Collet ER25

Rated voltage: 380V

Rated speed: 12.000 rpm

Max speed: 12.000rpm

Rotation: Right

MT1073 - Y6162Y0007

Kw 1,50-S1/1,80-S6

connection ER25 collet - 18.000rpm - rated voltage 380V - right rotation

MT1073 - Y6162Y0007

TECHNICAL SPECIFICATIONS

Power S1/S6: 1Kw/1,30Kw

Connection type: Collet ER25

Rated voltage: 380V

Rated speed: 18.000 rpm

Max speed: 18.000rpm

Rotation: Right

MT1073 - Y6162Y0041

Kw 1,50-S1/1,80-S6

connection ER25 collet - 18.000rpm - rated voltage 380V - right rotation

MT1073 - Y6162Y0041

TECHNICAL SPECIFICATIONS

Power S1/S6: 1Kw/1,30Kw

Connection type: Collet ER25

Rated voltage: 380V

Rated speed: 18.000 rpm

Max speed: 18.000rpm

Rotation: Right

MT1073 - Y6162Y0008

Kw 1,50-S1/1,80-S6

connection ER25 collet - 18.000rpm - rated voltage 380V - right rotation

MT1073 - Y6162Y0008

TECHNICAL SPECIFICATIONS

Power S1/S6: 1Kw/1,30Kw

Connection type: Collet ER25

Rated voltage: 380V

Rated speed: 18.000 rpm

Max speed: 24.000rpm

Rotation: Right

MT1073 - Y6162Y0009

Kw 1-S1/1,30-S6

connection ER25 collet - 12.000rpm - rated voltage 220V - right rotation

MT1073 - Y6162Y0009

TECHNICAL SPECIFICATIONS

Power S1/S6: 1Kw/1,30Kw

Connection type: Collet ER25

Rated voltage: 220V

Rated speed: 12.000 rpm

Max speed: 12.000rpm

Rotation: Right

MT1073 - Y6162Y0054

Kw 1,10-S1/1,38-S6

connection ER25 collet - 18.000rpm - rated voltage 380V - right rotation

MT1073 - Y6162Y0054

TECHNICAL SPECIFICATIONS

Power S1,10/S6: 1Kw/1,38Kw

Connection type: Collet ER25

Rated voltage: 380V

Rated speed: 18.000 rpm

Max speed: 18.000rpm

Rotation: Right

MT1073 - Y6162Y0047

Kw 1,10-S1/1,38-S6

connection ER25 collet - 18.000rpm - rated voltage 380V - right rotation

MT1073 - Y6162Y0047

TECHNICAL SPECIFICATIONS

Power S1/S6: 1Kw/1,38Kw

Connection type: Collet ER25

Rated voltage: 380V

Rated speed: 18.000 rpm

Max speed: 24.000rpm

Rotation: Right

MT1073 - Y6162Y0012

Kw 2-S1/2,40-S6

connection ER25 collet - 12.000rpm - rated voltage 380V - right rotation

MT1073 - Y6162Y0012

TECHNICAL SPECIFICATIONS

Power S1/S6: 2Kw/2,40Kw

Connection type: Collet ER25

Rated voltage: 380V

Rated speed: 12.000 rpm

Max speed: 12.000rpm

Rotation: Right

MT1073 - Y6162Y0015

Kw 2-S1/2,40-S6

connection ER25 collet - 12.000rpm - rated voltage 220V - right rotation

MT1073 - Y6162Y0015

TECHNICAL SPECIFICATIONS

Power S1/S6: 2Kw/2,40Kw

Connection type: Collet ER25

Rated voltage: 220V

Rated speed: 12.000 rpm

Max speed: 12.000rpm

Rotation: Right

AT1073 - Y6164Y0007

Kw 0,42-S1/0,50-S6

connection Keyed - 12.000rpm - rated voltage 380V - right rotation

AT1073 - Y6164Y0007

TECHNICAL SPECIFICATIONS

Power S1/S6: 0,42Kw/0,50Kw

Connection type: Keyed

Rated voltage: 380V

Rated speed: 12.000 rpm

Max speed: 12.000rpm

Rotation: Right

AT1073 - Y6164Y0009

Kw 0,75-S1/0,90-S6

connection Keyed - 12.000rpm - rated voltage 380V - right rotation

AT1073 - Y6164Y0009

TECHNICAL SPECIFICATIONS

Power S1/S6: 0,75Kw/0,90Kw

Connection type: Keyed

Rated voltage: 380V

Rated speed: 12.000 rpm

Max speed: 12.000rpm

Rotation: Right

AT1073 - H6164H0013

Kw 0,80-S1/0,96-S6

connection Keyed - 12.000rpm - rated voltage 380V - right rotation

AT1073 - H6164H0013

TECHNICAL SPECIFICATIONS

Power S1/S6: 0,80Kw/0,96Kw

Connection type: Keyed

Rated voltage: 380V

Rated speed: 12.000 rpm

Max speed: 12.000rpm

Rotation: Right

AT1073 - H6164H0012

Kw 1,00-S1/1,30-S6

connection Keyed - 12.000rpm - rated voltage 380V - right rotation

AT1073 - H6164H0012

TECHNICAL SPECIFICATIONS

Power S1/S6: 1,00Kw/1,30Kw

Connection type: Keyed

Rated voltage: 380V

Rated speed: 12.000 rpm

Max speed: 12.000rpm

Rotation: Right

AT1073 - H6164H0011

Kw 2,00-S1/2,40-S6

connection Keyed - 12.000rpm - rated voltage 380V - right rotation

AT1073 - H6164H0011

TECHNICAL SPECIFICATIONS

Power S1/S6: 2,00Kw/2,40Kw

Connection type: Keyed

Rated voltage: 380V

Rated speed: 12.000 rpm

Max speed: 12.000rpm

Rotation: Right

AT1055 - H6164H0015

Kw 0,65-S1/0,85-S6

connection Keyed - 12.000rpm - rated voltage 380V - right rotation

AT1055 - H6164H0015

TECHNICAL SPECIFICATIONS

Power S1/S6: 0,65Kw/0,85Kw

Connection type: Keyed

Rated voltage: 380V

Rated speed: 12.000 rpm

Max speed: 12.000rpm

Rotation: Right

AT1055 - H6164H0022

Kw 0,65-S1/0,85-S6

connection Keyed - 12.000rpm - rated voltage 380V - right rotation

AT1055 - H6164H0022

TECHNICAL SPECIFICATIONS

Power S1/S6: 0,65Kw/0,85Kw

Connection type: Keyed

Rated voltage: 380V

Rated speed: 12.000 rpm

Max speed: 12.000rpm

Rotation: Right

AT1055 - H6164H0020

Kw 0,65-S1/0,85-S6

connection Keyed - 12.000rpm - rated voltage 380V - right rotation

AT1055 - H6164H0020

TECHNICAL SPECIFICATIONS

Power S1/S6: 0,65Kw/0,85Kw

Connection type: Keyed

Rated voltage: 380V

Rated speed: 12.000 rpm

Max speed: 12.000rpm

Rotation: Right

View File

MT1073 - H6162H0133

Kw 3-S1/3,60-S6 - connection ER25 collet

24.000rpm - rated voltage 380V - right rotation - side fixing

MT1073 - H6162H0133

TECHNICAL SPECIFICATIONS

Power S1/S6: 3Kw/3,60Kw

Connection type: Collet ER25

Rated voltage: 380V

Rated speed: 18.000 rpm

Max speed: 24.000rpm

Rotation: Right

Side fixing holes

MT1073 - Y6162Y0013

Kw 3-S1/3,60-S6

connection ER25 collet - 18.000rpm - rated voltage 380V - right rotation

MT1073 - Y6162Y0013

TECHNICAL SPECIFICATIONS

Power S1/S6: 3Kw/3,60Kw

Connection type: Collet ER25

Rated voltage: 380V

Rated speed: 18.000 rpm

Max speed: 18.000rpm

Rotation: Right

MT1073 - Y6162Y0069

Kw 3-S1/3,60-S6

connection ER25 collet - 18.000rpm - rated voltage 380V - left rotation

MT1073 - Y6162Y0069

TECHNICAL SPECIFICATIONS

Power S1/S6: 3Kw/3,60Kw

Connection type: Collet ER25

Rated voltage: 380V

Rated speed: 18.000 rpm

Max speed: 18.000rpm

Rotation: Left

MT1073 - Y6162Y0014

Kw 3-S1/3,60-S6

connection ER25 collet - 18.000rpm - rated voltage 380V - right rotation

MT1073 - Y6162Y0014

TECHNICAL SPECIFICATIONS

Power S1/S6: 3Kw/3,60Kw

Connection type: Collet ER25

Rated voltage: 380V

Rated speed: 18.000 rpm

Max speed: 24.000rpm

Rotation: Right

MT1073 - Y6162Y0071

Kw 3-S1/3,60-S6

connection ER25 collet - 18.000rpm - rated

MT1073 - Y6162Y0071

TECHNICAL SPECIFICATIONS

Power S1/S6: 3Kw/3,60Kw

Connection type: Collet ER25

Rated voltage: 380V

Rated speed: 18.000 rpm

Max speed: 24.000rpm

Rotation: Right

MT1073 - Y6162Y0016

Kw 3-S1/3,60-S6

connection ER25 collet - 18.000rpm - rated voltage 220V - right rotation

MT1073 - Y6162Y0016

TECHNICAL SPECIFICATIONS

Power S1/S6: 3Kw/3,60Kw

Connection type: Collet ER25

Rated voltage: 220V

Rated speed: 18.000 rpm

Max speed: 18.000rpm

Rotation: Right

MT1073 - Y6162Y0050

Kw 3-S1/3,60-S6

connection ER25 collet - 18.000rpm - rated voltage 220V - left rotation

MT1073 - Y6162Y0050

TECHNICAL SPECIFICATIONS

Power S1/S6: 3Kw/3,60Kw

Connection type: Collet ER25

Rated voltage: 220V

Rated speed: 18.000 rpm

Max speed: 18.000rpm

Rotation: Left

MT1073 - Y6162Y0017

Kw 3-S1/3,60-S6

connection ER25 collet - 18.000rpm - rated

MT1073 - Y6162Y0017

TECHNICAL SPECIFICATIONS

Power S1/S6: 3Kw/3,60Kw

Connection type: Collet ER25

Rated voltage: 220V

Rated speed: 18.000 rpm

Max speed: 24.000rpm

Rotation: Right

MT1073 - Y6162Y0057

Kw 2,10-S1/2,80-S6

connection ER25 collet - 18.000rpm - rated voltage 380V - right rotation

MT1073 - Y6162Y0057

TECHNICAL SPECIFICATIONS

MT1073 - Y6162Y0034

Kw 2,10-S1/2,80-S6

connection ER25 collet - 18.000rpm - rated voltage 380V - right rotation

MT1073 - Y6162Y0034

TECHNICAL SPECIFICATIONS

Power S1/S6: 2,10Kw/2,80Kw

Connection type: Collet ER25

Rated voltage: 380V

Rated speed: 18.000 rpm

Max speed: 24.000rpm

Rotation: Right

MT1073 - Y6162Y0058

Kw 2,10-S1/2,80-S6

connection ER25 collet - 18.000rpm - rated voltage 220V - right rotation

MT1073 - Y6162Y0058

TECHNICAL SPECIFICATIONS

Power S1/S6: 2,10Kw/2,80Kw

Connection type: Collet ER25

Rated voltage: 220V

Rated speed: 18.000 rpm

Max speed: 18.000rpm

Rotation: Right

MT1073 - Y6162Y0040

Kw 2,10-S1/2,80-S6

connection ER25 collet - 18.000rpm - rated voltage 220V - right rotation

MT1073 - Y6162Y0040

TECHNICAL SPECIFICATIONS

Power S1/S6: 2,10Kw/2,80Kw

Connection type: Collet ER25

Rated voltage: 220V

Rated speed: 18.000 rpm

Max speed: 24.000rpm

Rotation: Right

View File

View File

View File
